6000W Luxpower Solar Ready Hybrid Inverter Trolley 5.12 KWh Shoto Lithium Battery+Wifi
Lead Time 2-3 Business days
Available online & in-store
Delivery estimated within 20/11 and 29/11
There are The perfect solution for load shedding!
The all-in-one portable plug & play inverter battery trolley system (Heavy Duty Inverter Trolley) Easy portable compact unit with lock wheels as well as handles to carry the system.
PLEASE NOTE TROLLEYS TAKE 2-3 HOURS TO ASSEMBLE
What is an all-in-one portable plug & play Solar Ready inverter system and what does it do?
It is an inverter unit connected to a battery that provides power when there is load shedding. It will charge your battery once the power is on. As soon as load shedding hits, your inverter system instantly transfers over to battery power. This will allow you to keep your lights, TV, computers, chargers, and WIFI running during load shedding. Solar ready : Add a solar panel and charge your batteries when there is no power.
How much battery backup power will I have when the power is off?
If you connect 150w which is usually a TV, WIFI, Lights, etc. This portable system will last 45-50 Hours With a 100% DOD.
Inverter Specifications:
General
- Model: SNA 6000 WPV
- Battery voltage: 48VDC.
Inverter Output
- Waveform: Pure Sine-Wave.
- Rated Power: 6000W.
- Parallel Capability: Yes, 16 units.
- AC Voltage Regulation (Battery Mode): 230VAC ± 5% @ 50/60Hz.
- Surge Power: 9000w.
- Efficiency (Peak): 93%.
- Transfer Time: 10 ms (For Personal Computers); 20 ms (For Home Appliances).
Solar Charger
- Maximum PV Array Power: 8000W.(4000w per MPPT)
- 2 MPPT Controllers
- MPPT Range @ Operating Voltage: 120VDC ~385 VDC.
- Maximum PV Array Open Circuit Voltage: 480VDC.
- Start Up Voltage: 100vdc
- Maximum Efficiency: 98%.
- Maximum Solar Charge Current: 17A/17A.
AC Charger
- Charge Current: 80A.
- AC Input Voltage: 230 VAC.
- Selectable Voltage Range: 110-280 VAC (For Personal Computers); 90-280 VAC (For Home Appliances).
- Frequency Range: 50Hz/60Hz (Auto sensing)
Battery Specifications:
- Battery Chemistry: LiFePO₄ (Lithium Iron Phosphate)
- Nominal Voltage: 48V
- Capacity: 100Ah
- Energy Storage: 5.12kWh
- Cycle Life: >6000 cycles at 80% DoD
- Max Charge Voltage: 54V
- Discharge Cutoff Voltage: 42V
- Maximum Charge/Discharge Current: 100A
- Round-Trip Efficiency: >95%
- Communication Protocols: RS485, CAN
- Operating Temperature: -20°C to 55°C
- Scalability: Parallel & Series connections supported
Size & Weight of The System :
50 X 61 X 61 CM
69 kg
This all-in-one system Includes:
1x Luxpower 6kW Off-Grid Inverter+Wifi Dongle (2 Years Warranty)
1x Shoto Lithium Iron Phosphate LiFePO4 51.2V 5.12KWH HP10-box5 Pro (10 Years Warranty)
1x Battery Fuse
1x 1m Power Cable With Wall Plug
1x 1m Cable With Power Socket
1x Heavy Duty Steel Portable Box With Lock Wheels & Handles
